** Please RSVP to email@example.com no later than Thursday, 04 April if you would like to attend.**
The DNSSEC Roadmap, prepared in February 2013 for the Department of Homeland Security’s DNSSEC Deployment Initiative, lays out a vision for where the Initiative should go and describes next steps that various actors should take to realize a world in which every zone is signed and every query is checked. It describes the state of the art of DNSSEC deployment in the U.S. and beyond, and includes pointers toward tools, technologies and strategies that both public and private-sector groups can use to increase that deployment.
This report, written in 2009 following the inaugural symposium of the DNSSEC Industry Coalition but unpublished until now, covers issues that remain important to ongoing DNSSEC deployment efforts. Written before the signing of the root zone, the “avoiding unintended consequences” section has been superseded by events, but the discussions of key distribution and use and key rollover remain as critical as ever for DNS and DNSSEC practitioners. [Note that this PDF contains comment markup from symposium participants.]
You probably use multiple DNS resolvers on multiple devices through the course of the day, as you wander to and from home, work, coffee shops, etc. Your desktop uses them. Your laptop uses them. Even your cellphone and tablets use them. But how well prepared are all of these resolvers for DNSSEC? Can they assist your applications in determining which DNS records have been secured or not?
By using the DNSSEC-Check tool from the DNSSEC-Tools project, you can find out! This handy utility will test your neighboring resolvers, and any additional ones you provide it, for their support of critical DNSSEC required protocol features. After testing is done, it will even provide you with a letter grade for each resolver. Ideally, every resolver should have an A grade (indicating that not only does it support DNSSEC queries, but is a DNSSEC validating resolver itself). But if not, the colored bubbles will quickly let you know exactly which features a resolver might be missing to be fully DNSSEC compliant.
Additionally, the DNSSEC-Check utility lets you submit your anonymized results to a results collection server. These collected results let the DNSSEC-Tools project track the state of world deployment over time. So, once you find out your local resolvers are not “quite up to the task”, then you can keep checking over time to see if they’ve been updated (or better yet, update them yourself if you can!). Then resubmit the results once things have changed! The results of this collection engine can be found on the DNSSEC-Check Results page. Submitting data is entirely optional, so thanks in advance if you are willing to help us out!
We sent a survey to ccTLD administrators about their adoption of DNSSEC. Below is a new animated map based on the initial flurry of responses we received. Many zones which we knew from observation to have their DS in the root turn out to be accepting delegations and are, therefore, fully operational! A high resolution PDF map is available here.
This animated GIF shows announced, estimated, and actual DNSSEC adoption by ccTLDs from January 2006 through July 2015 as of 1 February 2013. We’d like to see a more colorful, even completely green, map in the future. We also have a high-resolution PDF map of the world with ccTLD DNSSEC adoption as of 1 February 2013 here.
The maps are a work in progress. We’re pretty sure about the past and present. If you manage a ccTLD and have a schedule for deployment or have updates/corrections, let us know at info @ dnssec-deployment.org.
Arstechnica reports that a possible DNS cache poisoning attack was used against the Romanian (.ro) versions of popular sites like Google, PayPal and Microsoft. While the exact cause is unknown, cache poisoning is suspected since it involved multiple domain names, but not the whole of the .ro domain:
For a span of one to several hours on Wednesday morning, people typing Google.ro, Yahoo.ro, and Romanian-specific addresses for other sites connected to a website that was purportedly run by an Algerian hacker, according to numerous security blog posts, including this one from Kaspersky Lab. Researchers said the most likely explanation for the redirection is a technique known as DNS poisoning, in which domain name system routing tables are tampered with, causing domain names to resolve to incorrect IP addresses.
More information from Kaspersky Lab.
In the past, we’ve described how the graphic at the top of the DNSSEC Deployment web site let you know if you’re validating or not.
The Collateral Damage of Internet Censorship by DNS Injection (594KB PDF) by Anonymous, published in ACM SIGCOMM Computer Communication Review (Volume 42, Number 3, July 2012), looks at how
Some ISPs and governments (most notably the Great Firewall of China) use DNS injection to block access to “unwanted” websites. The censorship tools inspect DNS queries near the ISP’s boundary routers for sensitive domain keywords and inject forged DNS responses, blocking the users from accessing censored sites, such as twitter and facebook. Unfortunately this causes collateral damage, affecting communication beyond the censored networks when outside DNS traffic traverses censored links.
They point out that the techniques used are similar to Kaminsky-style attacks that can be perpetrated on non-DNSSEC-enabled systems:
In the absence of DNSSEC validation, the resolver will generally accept the faked answer because it arrives earlier than the real one, and, as a result, the access to the sensitive site will be blocked or redirected.
While DNSSEC is not able to guarantee transport of valid queries and responses, the paper goes on to say how it prevents the collateral damage associated with such machinations.
The DNSSEC Deployment Initiative, in cooperation with the ICANN Security and Stability Advisory Committee (SSAC), is planning a DNSSEC Workshop at the ICANN meeting in Toronto, Canada on 17 October 2012. The DNSSEC Workshop has been a part of ICANN meetings for several years and has provided a forum for both experienced and new people to meet, present and discuss current and future DNSSEC deployments. For reference, the most recent session was held at the ICANN Prague meeting on 27 June 2012. The presentations and transcripts are available at http://prague44.icann.org/node/31749.
We are seeking presentations on the following topics:
1. DNSSEC Activities in North America
This is a key panel and we are seeking participation from those who have been involved in DNSSEC deployment in North America as well as those who have a keen interest in the challenges and benefits of deployment. Key questions are to consider include: what would help to promote DNSSEC deployment? What are the challenges you have faced when you deployed DNSSEC? Can DNSSEC make the information users receive more reliable?
2. ISPs and Validation
ISPs are beginning to take the first step to full DNSSEC implementation that will allow web users, with software applications like browsers, to validate that the destination they are trying to reach is authentic and not a spoofed website. We are seeking ISPs to participate in a panel discussion or provide presentations on their DNSSEC deployment plans, challenges, and benefits for users.
3. The Realities of Running DNSSEC
Now that DNSSEC has become an operational norm for many registries and registrars, what have we learned about how we manage DNSSEC? What’s best practice around key rollovers? How often do you review your disaster recovery procedures? Is there operational familiarity within your customer support teams? Has DNSSEC made DNS more ‘brittle’ or is it just a run-of-the-mill operational practice?
4. DNSSEC and Enterprise Activities
DNSSEC has always been seen as a huge benefit to organizations looking to protect their identity and security on the Web. Large enterprises are an obvious target for DNS hackers and DNSSEC provides an ideal solution to this challenge. This session aims to look at the benefits and challenges of deploying DNSSEC for major enterprises. Topics for discussion:
What is the current status of DNSSEC deployment among enterprises?
What plans do the major enterprises have for their DNSSEC roadmaps?
What are the challenges to deployment for these organizations? Do they foresee raising awareness of DNSSEC with their customers?
5. When Unexpected DNSSEC Events Occur
What have we learned from some of the operational outages that we have seen over the past 18 months? Are there lessons that we can pass on to those just about to implement DNSSEC? How do you manage dissemination of information about the outage? What have you learned about communications planning? Do you have a route to ISPs and registrars? How do you liaise with your CERT community?
6. DNSSEC in the Wild
What operational statistics have we gathered about DNSSEC? Is it changing DNS patterns? How are our nameservers handling DNSSEC traffic? Is the volume as expected? Have we seen anything unusual? Are there experiences being documented in the form of best practices, or something similar, for transfer of signed zones?
7. DANE and other DNSSEC applications
Using DNSSEC as a means of authentication for http transactions is an exciting development of DNSSEC. What is the progress of the DNS-Based Authentication of Named Entities (DANE) initiative? (See http://datatracker.ietf.org/wg/dane/.) How soon could DANE become a deployable reality and what will be the impact of such a deployment, e.g. impact on traditional certification authorities (CAs)?
8. The Great DNSSEC Panel Quiz
Ever fancied pitting your wits against your colleagues? Demonstrate your knowledge and expertise in DNSSEC in our Great DNSSEC Panel Quiz.
In addition, we welcome suggestions for additional topics.
If you are interested in participating, please send a brief (1-2 sentence) description of your proposed presentation to firstname.lastname@example.org by **Monday, 23 July 2012.**
We hope that you can join us.
On behalf of the DNSSEC Workshop Program Committee:
Steve Crocker, Shinkuro
Jacques Latour, .CA
Simon McCalla, Nominet UK
Russ Mundy, Sparta/Parsons
Ondřej Surý, CZ.NIC
Lance Wolak, .ORG, The Public Interest Registry
